2023 TERYX KRX 1000
2023 Kawasaki TERYX KRX 1000 for Sale at Moorooka Kawasaki in Moorooka, QLD | Specifications and Review Information
lt from the ground up to be the ultimate sport side by side, the Teryx KRX 1000 is not to be denied by the world's toughest trails. The game-changing Teryx KRX 1000 inspires confidence with a terrain-taming combination of power, performance and capability. Add in an unprecedented level of comfort and the superior build quality of Kawasaki side by sides, and you've got everything you need to push the limits for an adventure of a lifetime
FEATURING:
- Powerful, high-torque 999 cc parallel-twin engine
- Massive ground clearance and long-travel suspension
- Highly rigid frame with integrated roll-over protective structure (ROPS)
CHASSIS DESIGNED FOR HARDY PERFORMANCE
Wheels positioned as far apart as possible contribute to the KRX 1000's overall stance. Its long 2,510 mm (99") wheelbase, combined with the long wheel travel, contributes to its performance and ride comfort, while its wide stance helps the vehicle maintain its line when cornering. (Tread measures 1,505 mm (59") at the front; 1,510 mm (59") at the rear.)
(Non-current colour shown)
CONFIDENCE
Backed by renowned Teryx durability and reliability, both the engine and frame of the KRX 1000 were designed to withstand tough conditions without being compromised. High build quality is complemented by extensive undercarriage protection, while on-the-fly-adjustable power delivery, including Power Mode selection, and a wide rear carrier large enough to accommodate a spare wheel add to peace of mind.
COMFORT
As the latest evolution of Kawasaki's Teryx side by side models, it should come as no surprise that the KRX 1000 was also designed to deliver superior comfort. Roomy interior space and ground-hugging suspension that soaks up bumps encountered on the trail mean driver and passenger can strap into the high-backed bucket seats and simply enjoy the ride.
(Non-current colour shown)
| Maximum Power | 84 kW {114 PS} / 8,500 rpm |
| Maximum Torque | 104 Nm {10.6 kgfm} / 7,000 rpm |
| Engine | 4-stroke Parallel Twin |
| Displacement | 999 cc |
| Bore x Stroke | 92.0 x 75.1 mm |
| Compression Ratio | 11.5:1 |
| Valve System | DOHC, 4 valves per cylinder |
| Fuel System | Fuel injection: Ø50 mm x 2 |
| Ignition | Digital |
| Starting | Electric |
| Cooling | Liquid-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | Dual-range (high/low) CVT with centrifugal clutch and reverse |
| Primary Reduction Ratio | 2.785 ~ 0.743 (belt converter) |
| Gear Ratio: Forward (High) | 4.504 (32/30 x 38/18 x 32/16) |
| Gear Ratio: Forward (Low) | 8.867 (42/20 x 38/18 x 32/16) |
| Gear Ratio: Reverse | 6.756 (32/20 x 38/18 x 32/16) |
| Final Reduction Ratio: Front | 3.589 (25/24 x 20/19 x 36/11) |
| Final Reduction Ratio: Rear | 3.538 (46/13) |
| Final Drive | 2WD/4WD, shaft |
| Frame | Ladder type, tubular steel |
| Front Suspension | Double wishbone, FOX 2.5 LSC Piggyback Shocks, fully adjustable preload, and 24-position adjustable compression damping |
| Rear Suspension | 4-link trailing arm rear suspension, FOX 2.5 LSC Piggyback Shocks, fully adjustable preload, and 24-position adjustable compression damping |
| Front Wheel Travel | 472 mm |
| Rear Wheel Travel | 536 mm |
| Steering | Rack and pinion with Electric Power Steering |
| Rake | 10.0° |
| Trail | 65 mm |
| Steering Angle (L/R) | 34° (IN) / 29° (OUT), 34° (IN) / 29° (OUT) |
| Front Tyres | MAXXIS Carnivore 31 x 10.00R15 8PR, with bead-lock wheels |
| Rear Tyres | MAXXIS Carnivore 31 x 10.00R15 8PR, with bead-lock wheels |
| Front Brakes | Dual Ø258 mm discs |
| Front Calipers | Dual twin-piston (Ø32 mm x2) |
| Rear Brake/s | Dual Ø258 mm discs |
| Rear Caliper/s | Dual single-piston (Ø38 mm x1) |
| Parking Brake | Auto-adjust mechanical disc |
| Dimensions (LxWxH) | 3,305 x 1,730 x 1,900 mm |
| Wheelbase | 2,510 mm |
| Road Clearance | 360/375 mm (standard/max preload) |
| Seat Height | 800 mm |
| Curb Mass** | 860 kg |
| Fuel Capacity | 40 litres |
| Tread Front / Rear | 1,505 mm / 1,510 mm |
| Turning Radius | 6.2 m |
| Cargo Bed Dimensions (LxWxH) | 370 x 840 x 230 mm |
| Cargo Bed Capacity | 159 kg |
| Seating Capacity | 2 |
| Vehicle Load Capacity | 354 kg |
| Lighting | 2x LED headlights |
| Model Code | KRF1000APFNN |
